Industrial Automatic Overhead PVC Curtain High Speed Revoling Shutterfor Warehouse or Factory

Our Laser scanner for safety protection, safety laser scanner applications, light curtain regulations is manufactured under the direction of high quality requirements, standard inspections and rich experience. With the business philosophy of 'quality service promotes product sales', we forge ahead in the industry. The high-quality service solves the worries for many users and wins the high praise and trust of them! You are sincerely welcome to go to our company to talk company face to face with each other and create long-term co-operation with us!

The density of the light beam determines how large the body part can be detected through the light curtain. According to ergonomic data, the diameter of the fingers of an adult should be no less than 14mm, the thickness of the palm should be no less than 30mm, and the diameter of the wrist should be no less than 40mm. For example: if the optical axis spacing of the light curtain used is 80mm, the optical axis diameter is 20mm, its resolution is 80-20=60mm, then fingers, palms, wrists and arms may pass through the light curtain without being detected. Therefore, if you want to obtain higher security, you need to use a higher resolution light curtain.

Ir sensor light curtain technical parameters

automation direct light curtain heating power supply: 24v 10A

Safety photoelectric sensor light curtain height: 50mm-2840mm

Main thermostat: disk package

Sealing temperature: 4℃

Disconnect temperature: 29℃

Spare thermostat: shutdown temperature — 55℃, disconnection temperature — 36℃

Beam spacing: 10/14/20/25/30/40 / 80mm (customizable)

Humidity switch: mechanical nylon membrane trigger switch

Relative humidity: 20-80%

Safety light curtain mirrors indicator light: when the heating element is turned on, the front red LED light is on

Safety light curtain detection structure: housing [stainless steel or aluminum alloy], windows [heated glass]

Working temperature: working [-20~+70℃ (no freezing)]

Safety light curtain selection diagram

Light curtain sensor wiring diagram

FAQ:

1. What configurations do you have for each set of safety light beam?

Standard configuration: one transmitter, one transmitter, two data lines, 4 right angle frames and one package of T screws;

2. Are you a brand of your own?

Yes, our brand name is CYNDAR, has patent authentication, and also provides OEM services.

3. Is the security light curtain/safety optical sensor customizable?

  Yes

4. What are the payment terms?

We deliver on delivery.

You can pay through Paypal, or a company account.

5. When will it be delivered?

Answer: 1) Sample 1-5 days 2) Mass production 7-15 days.

Through experienced industry sales and service teams, many industry users can use our Industrial Automatic Overhead PVC Curtain High Speed Revoling Shutterfor Warehouse or Factory to improve the efficiency of their respective businesses and enhance their competitiveness. We provide personalized services according to the characteristics of different types of customers, and proactively formulate perfect service standards for more customers. Our tenet is 'Reasonable prices, efficient production time and best service' We hope to cooperate with more customers for mutual development and benefits.
