Product Parameters
Model: XD-TOF-10HM | Detection distance @90% reflectivity: 100cm |
Detection accuracy: ±3cm | Scanning area: 270° |
Laser point distance merge: n/a | Scanning frequency frame: 20Hz |
Minimum resolution: 0.32° (fixed) | EMF: DC 12 V-24 V |
Laser light source: 905 nm class I | Power: 2W |
Data transmission interface: 50000Lux | Size: 50*50*76mm |
Weight: 148g (without cable) | Protection level: IP67 |
Product Description
1) Time of flight detection technology
2) Measuring length 10m
3) 271° saccade, angular resolution 0.32°
4) Lux: 50,000
5) Nano dust cover reduces maintenance time.
6) Meet human eye safety requirements
7) IP65 protection level
8) A variety of installation methods to facilitate users' secondary development
Performance
Software Diagram
Product Size
Scene Application
Danger point protection on loading and unloading doors
On the CNC machine tool, the slide table is used to send the workpiece into the processing area. The XD-TOF-05D safety laser scanner can be installed on the upper end of the door valve of the CNC machine tool for protection. The laser sensor touches the dangerous area, and the radar sensor issues a warning. It can also be installed under the roller conveyor to protect the dangerous area below and reduce the complexity and danger of automation.
