Features of lidar indoor navigation
lidar based navigation 270° two-dimensional plane scanning detection, the distance can be measured 25m
The accuracy is not affected by the detection distance, and the detection accuracy reaches +/- 3cm
Strictly limit laser power to ensure human eye safety
Application field
Autonomous positioning and navigation of service robots and sweeping robots
AGV navigation and obstacle avoidance, regional security
Parameter
|
Number: XD-TOF-20D |
Power supply voltage: DC9V-28V |
|
Power consumption <3W |
Measurement error: ±30 mm |
|
Angle resolution: 0.1°/0.3° |
Recognition angle: 270° |
|
Editable warning area: 3 |
Ambient light resistance: <15,000 lux |
|
Micro USB is not yet activated |
Switch drive:DC30V, 50mA MAX |
|
I/O |
Working temperature range: -10℃-55℃ |
Product Advantages
Software Diagram
Scanning Range/Reflection
Product Description
1. Defensive glare <15000lux
2. Interface: Micro-USB
3. Multi-layer protection area can be set
4. Editable warning area: 3
5. Based on TOF pulse measurement technology
6. Ranging capability up to 20m
7. Eye safety technology
Product Size
Equipment Accessories And Interfaces
Applications
The XD-TOF-20D LiDAR scanner offers a variety of industrial applications.
Specific application scenarios
Robot workstations and automated production lines
In automated production lines such as welding robots and assembly machinery, the safety laser scanner XD-TOF-20D is usually placed around the machine or at the door area. When an operator or foreign object enters these monitoring areas, the safety laser scanner will immediately send a signal to stop the machine from working to prevent collisions or pinching accidents.
