Parameter
|
Number: XD-TOF-05D |
Detection range: 0.5-5M |
|
Venue use: indoor |
Available angle: 270° |
|
Scanning frame rate: 15 Hz/30 Hz |
Minimum angular resolution: 0.1°/0.3° |
|
Accuracy error: ±3cm |
Continuous error: ±30 mm |
|
Levels of protection:IP65 |
Monitor the area / total area number simultaneously：3 regions / 16 group * 3 regions |
|
Status indicator: power indicator, status indicator |
Switch drive：DC30V, 50mA MAX |
|
OS: Windows 7 and Windows 10 CPU: Intel i5 dual-core 2.7G, and above |
|
Product Advantages
Product Description
1. Glare protection <15,000 lux
2. Interface: IO
3. Multiple protection zones can be set
4. Editable warning zones: 3
5. Based on TOF pulse measurement technology
6. Distance measurement capability up to 5 meters
7. Eye-safe technology
Applications
Vertical protection of fences
2D laser scanners can detect people crawling or crossing fences. 2D laser scanners can set vertical zones. If someone crosses the zone, the security scanner will trigger an alarm. Users can set an unlimited number of detection zones within the radar coverage area. When an intrusion occurs, the system will trigger an alarm and report the intrusion location to the user.
It can also be used to protect personnel at the perimeter of manipulators and dangerous equipment.
When a person enters the warning area, the scanner will output a signal. This signal can be used to control the manipulator or equipment to stop working
