l Safety Light Curtain for Manipulator for Woodworking Machinery
feature of product
1. Have a complete self-check system
2. Strong anti-interference ability: good anti-interference ability against electromagnetic signals, stroboscopic, welding arc and surrounding light sources.
3. Easy installation, adjustable, simple wiring, beautiful appearance, in line with European design standards
4. Has excellent impact resistance.
5. Type 4 IEC61496-1 / 2 standard and has passed CE certification Type 2, Type 4.
6. Short response time (≤15ms), safe and reliable.
7.30 * 30mm width and thickness, effectively reducing the installation space.
Wiring diagram
Introduction to the working principle of safety light curtain
Use the safety light curtain to detect objects (such as hands) entering the test principle structure. One side of the light curtain is equipped with multiple infrared emitting tubes at equal intervals, and the other side has the same number of infrared receiving tubes in the same arrangement. Each infrared emitting tube corresponds to the corresponding infrared receiving tube, and they are installed on the same straight line.
When the infrared emitting tube and the infrared receiving tube are in the same straight line and there is no obstacle, the modulation signal (optical signal) from the infrared emitting tube can reach the infrared receiving tube smoothly. After the infrared receiving tube receives the modulation signal, the corresponding internal circuit outputs low level. In the case of obstacles, the modulation signal (optical signal) sent by the infrared transmitting tube cannot reach the infrared receiving tube smoothly, and the infrared receiver tube cannot receive The signal is modulated, and the corresponding internal circuit output is high.
When there is no object in the light curtain, the modulation signal (light signal) sent by all infrared emitting tubes can reach the corresponding infrared receiving tube on the other side smoothly, so that all internal circuits output low level. In this way, the safety light sensor can detect the presence or absence of an object by analyzing the state of the
