Parameter
|
essential information |
||
|
product name |
XD-TOF-50H lidar |
|
|
model |
XD-TOF-50H |
XD-TOF-50H P |
|
Measuring properties |
||
|
detection zone |
0.1-50 m @ 90% reflectivity 0.1-20 m @ 10% reflectivity |
|
|
repeatability precision |
±20 mm |
|
|
scanning scope |
280° |
|
|
angular resolution |
0.08°/0.16°/0.32° |
0.32° |
|
Scan frame rate |
50 H z |
100 H z |
|
current-illumination characteristic |
||
|
supply voltage |
DC 9V -36 V |
|
|
working current |
0.225A / 12 V (typical) |
|
|
laser light source |
905 nm class I |
|
Applications
Environmental testing along the railway
Check whether there are branches and rocks on the outer size limit of the train, and objects blocking the safe operation of the vehicle. It is installed on the inspection vehicle by using 2D lidar, and can cooperate with the corresponding anti-collision system to early warning, detect or make corresponding control to ensure the safe and stable operation of the train.
