Light curtains have a very wide range of applications. For example, in the stamping equipment that requires continuous feeding and reclaiming, if a contact safety protection door is installed, the operator needs to open and close the protection door frequently, which not only increases the workload of the operator, but also reduces Increased production efficiency. In this case, the use of gratings and light curtains is the best choice. When the operator is sending and reclaiming materials, as long as any part of the body blocks the light, the machine will enter a safe state without causing injury to the operator.

Safety photoelectric sensor technical parameters

Connection：Circular aeronautical socket with special connection cable,4 cores wire for transmitter, 5 cores wire for receiver

Indication lights：Transmitter: Power supply indicates red,

Receiver: Output indicates green, shading: the light indicates red

Ambient light：Natural light: receiving surface 3000Lx; Sunlight: receiving surface 10000Lx

Power Supply：DC12/24V AC110—220V (relay output)

Housing Material：Aluminium alloy, End Cover: ABS reinforced nylon

Output Status：All optic axis turn ON once powered (shows green)

Output：NPN\PNP, input current 500mA,voltage drop: less than1.5V, reverse polarity, short-circuit, overload protection
