AGV Automotive Mechanical Rubber Safety Edge Sensor

AGV Automotive Mechanical Rubber Safety Edge Sensor

The safety edge is a sensor that protects people from injury when cutting and squeezing the edge. If the safety edge encounters an obstacle, for example, if a hand obstructs closing the door, it will immediately stop the automatic movement.

Product Introduction

Download the product brochure to view all parameters

For more information, please download the manual
For customization instructions, click "Safety Edge Customization Instructions"







The safety edge is a sensor that protects people from injury when cutting and squeezing the edge. If the safety edge encounters an obstacle, for example, if a hand obstructs closing the door, it will immediately stop the automatic movement.



parameter

Model: SESafety Edge Sensor

Detection method: pressure sensing method

Maximum sensing angle: <90°

Trigger force (according to specifications and uses): ≥50N-250N

Mechanical life: >3,000,000 times

Surface protection layer material: TPE elastomer, EPDM rubber

Ambient temperature: -20°-50°

Protection level: IP65

Maximum humidity (23°) 95% (condensation)

Response time: 13ms



PSE type safety edge contact sensor and SRC106 type safety relay form a safety edge contact system





05c15dd768d2d3bb5a1f6d507437c2e



d3e738554081e500b8348d3042e8a3a



11

2

3

4

5

6

1

AGV safety edge application 01



Restrictions on the use of safe touch edges

1) The safety edge contact protection system is not suitable for the protection of machines against human injuries in fast-moving situations.

2) For different applications, please select safety carpets according to the regulations in this manual.

3) Please select the matching safety relay according to this technical manual. Different safety relays will affect the trigger sensitivity of the safety contact.

4) Please configure the safety edge contact system according to this technical manual to ensure the functional safety of the safety edge contact system.

5) Special-shaped installation must comply with the restricted technical data in the manual.

6) Please contact our company for customizing the safety edge application in special fields.



product description

Reminder:

1. Dear, you can collect us more and contact us so as to keep abreast of the latest and best products we provide you.

2. The size is measured manually with slight error.

3. Purchase AGV automotive mechanical rubber safety edge sensor

After success, we will ship the goods as soon as possible. You can receive it 7-10 days after delivery. 6All the products of our company are brand new products, the shipping place is in China, and the warranty is 18 months





Hot Tags: agv automotive mechanical rubber safety edge sensor, China, manufacturers, factory, buy, price, cheap, safety edges on swing gates, safety contact edge, safety edge bumper switch
