Introduction
1. The switch provides DC30V 50mA driving force
2. Automatically detect the environment
3. Environment illumination range≤50000Lux
4. Vibration resistance: amplitude 0.75mm, XYZ triaxiality, 2 hours per axis
5. IP65 dustproof and waterproof
Product Parameters
Model: XD-TOF-05D | Self-learning function: the environment automatically scans and generates areas |
Angle resolution: 0.1°/03° | Scanning frame rate: 15Hz/30Hz |
Number of regional settings: 16 | Each area group contains 3 alert areas |
Rotation angle: 270° | Working range: 0.05m-5m |
Energy supply: 2W | Working voltage: DC9C-28C |
Vibration resistance: 50-200Hz, 196m/s² (20G), scanning speed 2min/x cycle, XYZ triaxial, 2 hours per axis | |
Product Advantages
Forklift Safety Protection
Use 05D laser scanner (detection range 0~270 degrees, detection distance 0~5m adjustable) to form a safety protection device to ensure safe operation. The brake stop of an obstacle is detected within the range of 0.2～0.5 meters. When it is detected that the obstacle enters the safety warning area, the AGV slows down and raises a warning sound; when it is detected that the obstacle enters the danger area, the AGV automatically stops, and automatically resumes operation after the obstacle is removed. AGV has offline protection and automatic correction of deviation from the track.
