The LIADR-100W module uses 3D TOF imaging for distance measurement. The distance noise is limited by the contour and depth of the measured object. This noise is also called time noise and varies with each measurement. Since the noise is a statistical value, its influence can be reduced by filtering. The factory default state of the LIADR-100W module is to directly output the measurement results without any filtering processing to ensure the fastest dynamic measurement response
CYNDAR has launched a new generation of high-performance proximity and ranging sensors based on Time of Flight (ToF) technology.
Unlike other proximity sensors that use simple IR (infrared) technology, which only measures the signal strength and is affected by the reflectivity of the object, the TOF flight sensor directly measures the distance to the object according to the time when the emitted photon is reflected, so that regardless of the object No matter the surface characteristics of the product, the distance can be accurately measured.
The flight sensor products are packaged in "one-piece" miniature modules, which provide CYNDAR sensors with unparalleled ranging speed and reliability.
This advanced ToF solution combines the advantages of CYNDAR's unique technology with our mature in-house imaging process and high-volume packaging facilities. It is very suitable for the needs:
Accurate high-speed ranging
Low power consumption
Competitive system cost
Easy integration with flexible mechanical design
Specifications
Measuring range: 0.2m~12m (indoor 90% reflectivity)
Power supply voltage: 4.8-5.2V
Communication method: UART, I2C
Measurement accuracy: 20-350cm (±5cm) 351-1200cm (±1.5%cm)
Receiving viewing angle: half angle 1°
Sending viewing angle: half angle 2°
Minimum resolution: 1mm
Test frame rate: Max 500Hz
Anti-ambient light ability: 15KIux
Exposure time: 5us-5000us
Signal amplitude: 3400LSB-7000LSB
Working temperature -10℃-60℃
Excellent consistency
High frame rate, 500Hz ranging frequency
Low-cost ranging solution
Small countermeasures, easy to install, long service life
Different object reflectivity compensation
LED light source, eye safety
Corresponding to short and medium distance (0.2m-12m), multiple measurement modes
Time of flight distance sensor for detecting distance
Time of flight lidar for user presence detection
tof distance sensor is used to detect distance and length
tof sensor for inventory management
laser ranging sensor for liquid level and distance detection
tof laser sensor can be used for inventory management
